Okuma LU45-M Impact CNC Turning Center

× Bidding has ended on this item.
Ended
TIMED AUCTION

36,000 Cut Hours, 24" Hydraulic Chuck, 5" max Bar Capacity, Milling Capabilities

Prev Lot
  Lot # 14
Next Lot
Listing Image
  • Sold Auctioneer has chosen not to publish the price of this lot
Details
Location
Springfield, Illinois
Logistics
There will be a loading cost of $1,600.00 and will be automatically included on the sales invoice.

  • Lot # 14
  • System ID # 3691198
  • End Date Central Standard Time
  • Start Date Central Standard Time
  • Item # 3691199
Description

Okuma LU45-M Impact Turning Center (1998)



Cutting Hours: 36,000
X-Travel:17.32"
Z-Travel:82"
X-Travel: 12"
Z-Travel: 74"
Distance: 78"
Max Swing over bed: 33"
Max Turning Upper: 32"
Max Turning Lower: 21"
Cutting Length: 78"
Rapid Travers: 590 IPM

Main Spindle:
Bar capacity: 5" Max
Chuck Size: 24"
Chuck Type: Hydraulic
Chuck Description: Kitagawa 24" 3-Jaw
Spindle Bore: 5"
Spindle Speed: 1400 w/ 24" Chuck
Spindle Motor: 60 HP
Spindle Gear Ranges: 4

Second Spindle:
M-Spindle: YES (Upper Turret Only)
M-Spindle Motor: 10 HP
M-Speed: 2000

Turret(s):
Tool Position (Upper Turret): 12
Tool Position (Lower Turret): 10
Tooling attachment type: VDI (both turrets)

Control:
Okuma OSP-U100L CNC Control



 Equipped With



Tailstock (Manual)
Tailstock equipped with: #5 Taper, Live bearings
Milling Capabilities
